No.72-Hastelloy C22N06022 Sockelhuvudskruv

Hastelloy C-22 Chemical composition

Legering%NicrMofeWCoCmnSiVPS
CMin.balans14.51543
Max.16.51774.52.50.08110.350.040.03
C22Min.balans2012.522.5
Max.22.514.563.52.50.020.50.080.350.020.02

Hastelloy C-22 Physical properties


Densitet

8,9 g / cm ^

Smältpunkt

1325-1370 ° C

Hastelloy C-22 Alloy minimum mechanical properties (in the room temperature)


Legeringsstatus

Draghållfasthet Rm N / mm²

Yield strength          R P 0.2 N/mm²

Förlängning A 5%

Hastelloy C22

690

283

40

Karaktäristisk som nedan


Hastelloy C22 is a omnipotent of nickel, chromium and molybdenum mixed alloy, with better corrosion resistance performance than other alloys, for example, Hastelloy C276 alloy, C4 alloy and 625 alloy.

Hastelloy C22 have a good resistance performance to pitting, crevice corrosion and stress corrosion cracking, have excellent inoxidability water medium performance, including the wet-chlorine, nitric acid or oxidizing acid mixed acid with chloride ion. Meantime, Hastelloy C22 possesses perfect resistance to reduction and oxidation of processing enviroments, then it can be used in some complicated environment or with many different manufacture target factory depend on the omnipotent performance.

Hastelloy C22 possess prominent resistance performance to different chemical environments, including strong oxidizing matter, such as iron chloride, copper chloride, chlorine, heat pollution liquid(organic and inorganic), formic acid, acetic acid, acetyl oxide, sea water and salting liquid and so on.

Hastelloy C22 alloy can resist the grain boundary precipitate form when jointing heat affected zone, this performance made it can applied in many kinds of chemical processing.

Hastelloy C-22 Corrosion resistance


Hastelloy C22 alloy suit for many kinds of chemical process industry which contain the oxidizing medium and reductant. High molybdenum and chromium content make it can resist the chloride corrosion, and tungsten make this corrosion resistance better.

Hastelloy C22 is one of a few material that can resist the corrosion of moist chlorine, hypochlorite and chlorine dioxide, this alloyhave prominent corrosion resistanceto high concentration chlorate( iron chloride and copper chloride)

Hastelloy C-22 Application field


Hastelloy C22 is widely used in the chemical field and petrifaction field, such as the element of chloride organic and catalyze system. This material especially suit for high temperature environments, impure inorganic acid and organic acid (such as formic acid and acetic acid), sea-water corrosion environments.

Hastelloy C-22 Other application field


1. Acetic acid/acetyl oxide
2.Acid dipping
3.Cellophane paper manufactures
4.Chloride system
5. Complicated mixed acid
6. Electrogalvanizing groove roller
7.Expansion bellows

snabba detaljer


Ursprungsplats: Jiangsu, Kina (fastlandet)
Typ: Nickel Bar
Application: chemical, petrochemical, energy manufacturing and pollution control
Grade: Ni,Fe,Cr
Ni (Min): 50
Resistance (μΩ.m): Low
Pulver eller inte: Inte pulver
Ultimate Strength (≥ MPa): 690
Elongation (≥ %): 40
Model Number: hastelloy C-22
Varumärke: QFC, HPF
shape: strip,tube,pipe,sheet,wire,forging,
